Custom gear machining involves manufacturing gears to precise client specifications, including unique tooth profiles, dimensions, materials, and tolerances. Processes like hobbing, grinding, shaping, and CNC milling are used to produce high-performance gears for specialized applications—such as robotics, Agriculture, automotive, or Automation. This approach ensures optimal fit, durability, noise reduction, and load capacity, offering flexibility beyond standard off-the-shelf gears.
Our engineering team conducts Design for Manufacturability (DFM) review, evaluating process feasibility, achievable precision, inspection methods, and potential risks.
Provide a detailed quotation and clear lead time based on the process route, material cost, inspection requirements, and production capacity.
Develop samples according to the confirmed drawing and process plan, strictly following forging, heat treatment, tooth processing, and grinding procedures.
Execute mass production according to the approved process standards, with in-process control and in-machine measurement at key stages to ensure consistency.
Perform final inspection (100% or sampling) and provide accuracy reports, hardness profile reports, and dimensional inspection records.
Perform dedicated packaging as per customer requirements to ensure tooth surfaces are protected during transit, and deliver on schedule.
| Typical Materials | Industry Application | Accuracy Requirement (ISO Standard) | Common Module Range (mm) | Core Heat Treatment Process |
| 20MnCr5, 18CrNiMo7-6 | New Energy Vehicle Reducer | Grade 5-6 (Extremely High) | 1.5 - 3.0 (Miniaturized) | Vacuum low-pressure carburizing and quenching |
| 20CrMnTi, 8620H | Traditional Vehicle Transmission | Grade 6-7 (Very High) | 2.0 - 4.0 | Controlled atmosphere carburizing and quenching |
| 22CrMoH | Automotive Differential | Grade 7-8 (High) | 4.0 - 8.0(Relatively Large) | Carburizing and quenching |
| SNCM439 | Industrial Robot | Grade 3-5 (Ultra-precision) | 1.0 - 2.5 (Miniature) | Carburizing and quenching, or gas/ion nitriding |
| 42CrMo, 20CrMnTi | Agricultural Machinery Equipment | Grade 8-9 (Medium) | 3.0 - 10.0 | Quenching and tempering, or carburizing and quenching |
| 42CrMo, 34CrNiMo6 | Construction Machinery | Grade 8-9 (Medium) | 5.0 - 20 | Quenching and tempering, or medium/high frequency induction quenching |
One-stop custom gear solution in PTK
| Capability Item | Description / Range |
| Custom Gear Design | OEM/ODM based on Drawings (PDF/STEP/DWG) or Samples |
| Reverse Eng | Testing center for mapping unknown gear samples |
| Inspection | Renishaw CMM, Gear Testing Center, Metallographic analysis |
| MOQ | Flexible (Support Prototypes to Mass Production) |
| Lead Time | 7-15 days for samples, 25-35 days for batch orders |
